1.4” OLED 400×400 Circular Screen

Wholesale Price: As an OLED manufacturer, Go2Display can offer this circular AMOLED at factory price.

Popular: The market has shown that this size of a smartwatch is very popular, like Ticwatch S Smartwatch-Knight. You can use it safely on a watch or other wearable products.

Custom OLED Solution: We offer custom OLED display solutions based on your size, shape, interface, IC, FPC cable shape, etc.

SKU: GFO400400-1.4ANT Categories: ,

Free Sample available all time!

  • Accept Custom Display Solution
  • Offer 12 Months Warranty
  • ISO 9001:2001 and RoHS Compliant for All Products

Description

This 1.4” OLED screen is a circular module with AMOLED panel / Resolution of 400×400 / Optional Touchscreen / MIPI Interface / RM69330 built-in IC / FPC connector.

The high quality, low price product is always our long-term goal.



Technical Details

Download Product References Below
Product Datasheet: GFO400400-1.4ANT
Driver Datasheet: RM69330



Model / Series Name GFO400400-1.4ANT
Diagonal Dimension (Inches) 1.4
Dots WxH 400×400
Module Size WxHxD (mm) 38.83 x 38.21
LCD Active Area WxHxD (mm) 38.83 x 38.21
Display Mode AMOLED
Viewing Angle Left: 80 / Right: 80 / Top: 80 / Bottom: 80 degrees;
Contrast Ratio 100000:1
Brightness 350 cd/m2
Display Colors 16.7 M, 100% NTSC
IC RM69330
Interface Type MIPI Interface, 24 pins Connector
Touch Panel Optional
Logic Power Supply 2.8V
Operating Temperature -20 ~ 60 °C
Storage Temperature -30 ~ 70 °C

1.4'' OLED 400x400 Circular Screen image quality 1.4'' OLED 400x400 Circular Screen contrast ratio

More Details about this 1.4” Circular Screen

This 1.4-inch OLED display has a circular shape with a 400×400 resolution.

This AMOLED screen emits light from its own organic materials. This is why it has a high contrast ratio of 100,000:1, and a 160 degrees wide viewing angle.

It can also show all 16.7 million colours in the NTSC colour gamut. With 350 cd/m2 brightness, users can see bright and sharp images.

It has a MIPI interface and a built-in RM69330 driver IC. So, it is easy to use it as a display replacement for your existing products. It can also be easier to use if you add a capacitive touch panel.

Even when the temperature is under 0°C or above 40°C, it can still work well.



Custom OLED Solution

With all of the above benefits, this 1.4-inch circular AMOLED screen is perfect for smartwatches and other wearable devices that have limited space but need to show details.

Go2Display is ready to provide custom OLED display solutions to meet your specific requirements.

Contact us at sales@go2display.com who is always willing to work with you.

Additional information

Display Type

TFT – IPS

Diagonal Size (Inch)

5.5 inch

Resolution

240×240

Interface

MIPI

Touch Screen

Optional CTP or RTP
